Mini Temperature Calibration Bath
The ML-3100 Mini Bath utilizes semiconductor-based refrigeration technology and jet-stream agitation technology. It features an operating temperature range of -10°C to 102°C, with a bath diameter of 47 mm and a depth of 200 mm, equipped with an anti-splash rim at the opening. The unit delivers a temperature stability of ±0.005°C. The bath can be fitted with a dedicated suspension fixture for freezing and storing small-sized water triple-point cells. It is also capable of performing comparative calibration of short-stem thermometers. Its compact design ensures excellent portability.
Specifications
| Operating Temperature | Antifreeze: -10 ℃ to 102 ℃ (14°F to 245.6°F) at 23 ℃ (73.4°F) |
| Working Area | Diameter 47mm (1.85"), Depth 200mm (7.87") |
| Wetted Parts | 304 stainless steel |
| Liquid Volume | Approximately 0.8 liters (0.2 gal) |
| Stirring Method | Jet stirring |
| Temperature Control Method | Fully digital PID control |
| Display Resolution | 0.001 ℃ |
| Temperature Stability | ±0.005 ℃ /10min |
| Temperature Uniformity | ±0.01 ℃ |
| Heating Time | 35 minutes from 25°C(77°F) to 90°C(194°F) |
| Cooling Time | 60 minutes from 25°C(77°F) to -5°C(23°F) |
| Operating Voltage | 110VAC ±10%, 60Hz (Customizable Technical Specifications) |
| Rated Power | Approximately 160W |
| Dimensions | 170mm (6.7") x 230mm (9") x 350mm (13.8") |
| Net Weight | Approximately 13 kg (28.7 lb) |
